RSR Digital I/O Module Kit - Comes Assembled

SKU: 3200DIGASSMB

  • Sale
  • Regular price $38.95


This digital trainer provides all necessary features for experimentation and prototyping of digital circuits. The trainer can be purchased fully assembled or in kit form. The kit version is an intermediate level kit that requires soldering and comes with easy to follow instructions.

The digital trainer includes the following features:

�Power supply: The board can be powered two ways:

A. Using terminal block Vcc and GND

B. Using tie blocks Vcc and GND

�LEDs 1-8: Detects digital signal �1� or �0�

�Clock: Provides TTL compatible clock signal from external signal source

�8 � SPDT toggle DIP data switches: Generate digital signals, �H� is �1� and �L� is �0�

�Debounced push button switch outputs: Provides TTL compatible pulse

�2 x Debounced momentary pulse switches

�26 Screwless terminal blocks for easy circuit connection
