RSR Digital Electronics Laboratory Experiments

SKU: 31DELE

  • Sale
  • Regular price $93.80


Use design software available from the chip manufacturer.* Then down-load your design from the PC with the parallel port cable (included).

* Design software is available at the Xilinx website page:

Link to Xilinx Software

Comes with a user's manual containing a complete description of the board together with lab experiments, power supply and cable.

To download the following manual (Microsoft Word format), RIGHT click on the link. A window will open up next to the link: choose "Save Target As" (Explorer) or "Save Link As" (Netscape) to save the file.



PLDT-3 - Has The On-Board I/O Capability You Need:

•DIP Switches

•De-bounced Momentary Switches

•LEDs

•7-Segment Displays

•Lots of Connectors for Jumper-Wires and Ribbon Cables
