Electronix Express

9.7 mm Diameter Electret Condenser Microphone FET, 2 to 10V DC, 1K Ohm Impedance, 50 to 8 KHz Frequency

SKU: 26MPFET

  • Sale
  • $1.50
  • Output Type: Analog
  • Direction: Omnidirectional
  • Frequency Range: 50 ~ 8 KHz
  • Sensitivity: -42dB ±3dB @ 94dB SPL
  • S/N Ratio: 60dB
  • Impedance: 1k Ohms
  • Voltage Range: 2 ~ 10V DC
  • Current - Supply: 500 µA
  • Port Location: Top
  • Termination: PC Pins
  • Size / Dimension: 0.382" Dia (9.70mm)
  • Height (Max): 0.264" (6.70mm)
  • Shape: Circular
